STANDARD FEATURES
7000lb G.V.W.R.
3500lb (ea axle) G.A.W.R.
2" BULLDOG COUPLER (7000lb)
1/4" GRD. 30 SAFETY CHAINS W/SAFETY LATCH HOOK (2ea)
5000lb SWIVEL JACK
2-3500lb CAMBERED AXLES W/ 1 Elec. BRAKE
15" 5 on 5 WHITE SPOKE WHEELS
205/75R15 LOAD RANGE C TIRES
MULTI-LEAF SPRING SUSPENSION
9 1/2" X 72" ROLLED FORMED TEARDROP BACK FENDER
4" CHANNEL TONGUE (4.5lbs/ft)
4" CHANNEL FRAME (4.5 lbs/ft)
2" X 2" ANGLE IRON UPRIGHTS (1.65 lbs/ft)
2" X 2" ANGLE IRON TOP RAIL (1.65 lbs/ft)
2-1/2" X 2-1/2" ANGLE IRON CROSSMEMBERS (3.07 lbs/ft)
2" X 6" TREATED PINE FLOOR
D.O.T. STOP, TAIL, TURN and CLEARANCE LIGHTS
16 GA. 5 WAY DOUBLE INSULATED WIRE
SAND BLASTED FOR MAXIMUM PAINT ADHESION W/ ONE COAT OF PRIMER
2 COATS OF AUTOMOTIVE QUALITY ACRYLIC ENAMEL FINISH

AVAILABLE MODELS
5 X 10
5 X 12
5 X 14
