STANDARD FEATURES
G.V.W.R. 2995# GVWR
G.A.W.R. 3500# GAWR
2" BULLDOG COUPLER (7000 LB)
1/4" GRD. 30 SAFETY CHAINS W/SAFETY LATCH HOOK (2ea)
5000# SWIVEL JACK
3500# CAMBERED IDLER AXLE
15" 5 on 5 WHITE SPOKE WHEELS
205/75R15 LOAD RANGE C TIRES
MULTI-LEAF SPRING SUSPENSION
9 1/2 X 34 1/4 ROLLED FORMED W/ BACK FENDER
3" X 4" ANGLE IRON TONGUE (5.8 LBS/FT)
2-1/2 X 2-1/2 ANGLE IRON FRAME (3.07 LBS/FT)
2" X 2" ANGLE IRON UPRIGHTS (1.65 LBS/FT)
2" X 2" ANGLE IRON TOP RAIL (3.07 LBS/FT)
2-1/2" X 2-1/2" ANGLE IRON CROSSMEMBERS (3.07 LBS/FT)
2" X 6" TREATED PINE FLOOR
D.O.T. STOP, TAIL, TURN AND CLEARANCE LIGHTS
16 GA. 5 WAY DOUBLE INSULATED WIRE
FINISH (prep) SAND BLASTED FOR MAXIMUM PAINT ADHESION W/ ONE COAT OF PRIMER
FINISH TWO COATS OF AUTOMOTIVE QUALITY ACRYLIC ENAMEL

AVAILABLE MODELS
5 X 8
5 X 10
5 X 12
5 X 14
5 x 16
